Wuhan GDZX Power Equipment Co., Ltd
Add to Cart
ZX-BC Transformer turn ratio tester
ZX-BC Transformer turn ratio tester is an innovative product with compact size, more portable and easy to carry. Products are mainly applied to change than group test transformer, PT and CT polarity test, test speed, high accuracy.
Features
1. Lithium battery power supply or 100-240V AC power supply is self-adaptive. After one charge, more than 100 transformers can be continuously tested in the ratio group. The test process is simple and convenient.
2. It has the function of blind measurement, that is, to perform variable ratio and group test when there is no connection between high and low voltage.
3. Based on the test of conventional transformer, Z-type transformer and PT sample, the polarity test function of CT variable ratio is added, and the application field is wider
4. Wide range and high accuracy, the variable ratio measurement range can reach 10,000, and the test accuracy can be guaranteed 0.3% when the maximum value is 10,000.
5. It has perfect protection functions such as reverse connection protection and output short circuit protection.
6. 6-inch super industrial high-brightness color LCD screen, still visible under strong sunlight.
7. equipped with printer, facilitate data printing
8. It can be stored locally and on USB memory.
Technical Indicators
| 1.Range: | 0.9～10000 |
| 2.Accuracy: | ±(Reading×0.1%+2 words)(≤500) ±(Reading×0.2%+2 words)(>500≤3000) ±(Reading×0.3%+2 words)(>3000) |
| 3.Resolution ration: | 0.9～9.9999(0.0001) 10～99.999(0.001) 100～999.99(0.01) 1000～9999.9(0.1) 10000 and above(1) |
| 4.Working power supply The built-in battery or external charger, charger conditions of use,Input 100-240 VAC,50/60 HZ | |
| 5.Charging time | About 3 hr |
| 6.Instrument weight | 3.8 kg |
| 7.Instrument dimension | 325 mm(L)*225 mm(W)*125 mm(H) |
| 8.Use of temperature | -10℃～50℃ |
| 9.Relative humidity | ≤90%,No dew |
Test cases
Company introduction
Wuhan GDZX Power Equipment Co.,Ltd.is a manufacturer of power test equipment, integrating design, production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.
Service and Warranty
Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* The contract and the technical agreement to sign by both parties.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user’s questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others.
Warranty
* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.
* Our products are guaranteed with one year warranty and life-long tech support.
* Provide solutions within 24 hours when there is problems feedback from customer.
PACKING AND SHIPPING
(1)We will ship products within 5-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.
If you need detailed specification, please feel free to contact us.
